| Name
| Description
|
|---|
| Body A
| The first physical body used.
|
| Body B
| The second physical body used.
|
| Collisions Between Linked Bodies
| Whether the collision detection is enabled between the linked physical bodies.
|
| Num Velocity Steps Override
| Override for the number of solver velocity iterations to run, the total amount of iterations is the max of Scene.PhysicsNumVelocitySteps and this for all constraints in the island.
|
| Num Position Steps Override
| Override for the number of position velocity iterations to run, the total amount of iterations is the max of Scene.PhysicsNumPositionSteps and this for all constraints in the island.
|
| Simulate
| Whether to enable the constraint in the simulation. The property can be used to implement a breakable constraint.
|
| Linear XAxis
| Linear X-axis constraint mode.
|
| Linear XAxis Limit
| The limits of the linear axis X.
|
| Linear XAxis Friction
| The friction of linear axis X.
|
| Linear XAxis Motor
| The motor mode of linear axis X.
|
| Linear XAxis Motor Frequency
| Oscillation frequency when solving position target (Hz). Should be in the range (0, 0.5 * simulation frequency]. When simulating at 60 Hz, 20 is a good value for a strong motor. Only used for position motors.
|
| Linear XAxis Motor Damping
| Damping when solving position target (0 = minimal damping, 1 = critical damping). Only used for position motors.
|
| Linear XAxis Motor Limit
| Force range to apply in case of a linear constraint (N). Usually this is -mMaxForceLimit unless you want a motor that can e.g. push but not pull. Not used when motor is an angular motor.
|
| Linear XAxis Motor Target
| The target value of the linear axis X motor. It is a velocity or a position depending the mode.
|
| Linear YAxis
| Linear Y-axis constraint mode.
|
| Linear YAxis Limit
| The limits of the linear axis Y.
|
| Linear YAxis Friction
| The friction of linear axis Y.
|
| Linear YAxis Motor
| The motor mode of linear axis Y.
|
| Linear YAxis Motor Frequency
| Oscillation frequency when solving position target (Hz). Should be in the range (0, 0.5 * simulation frequency]. When simulating at 60 Hz, 20 is a good value for a strong motor. Only used for position motors.
|
| Linear YAxis Motor Damping
| Damping when solving position target (0 = minimal damping, 1 = critical damping). Only used for position motors.
|
| Linear YAxis Motor Limit
| Force range to apply in case of a linear constraint (N). Usually this is -mMaxForceLimit unless you want a motor that can e.g. push but not pull. Not used when motor is an angular motor.
|
| Linear YAxis Motor Target
| The target value of the linear axis Y motor. It is a velocity or a position depending the mode.
|
| Linear ZAxis
| Linear Z-axis constraint mode.
|
| Linear ZAxis Limit
| The limits of the linear axis Z.
|
| Linear ZAxis Friction
| The friction of linear axis Z.
|
| Linear ZAxis Motor
| The motor mode of linear axis Z.
|
| Linear ZAxis Motor Frequency
| Oscillation frequency when solving position target (Hz). Should be in the range (0, 0.5 * simulation frequency]. When simulating at 60 Hz, 20 is a good value for a strong motor. Only used for position motors.
|
| Linear ZAxis Motor Damping
| Damping when solving position target (0 = minimal damping, 1 = critical damping). Only used for position motors.
|
| Linear ZAxis Motor Limit
| Force range to apply in case of a linear constraint (N). Usually this is -mMaxForceLimit unless you want a motor that can e.g. push but not pull. Not used when motor is an angular motor.
|
| Linear ZAxis Motor Target
| The target value of the linear axis Z motor. It is a velocity or a position depending the mode.
|
| Angular XAxis
| Angular X-axis constraint mode.
|
| Angular XAxis Limit
| The limits of the angular axis X.
|
| Angular XAxis Friction
| The friction of angular axis X.
|
| Angular XAxis Motor
| The motor mode of angular axis X.
|
| Angular XAxis Motor Frequency
| Oscillation frequency when solving position target (Hz). Should be in the range (0, 0.5 * simulation frequency]. When simulating at 60 Hz, 20 is a good value for a strong motor. Only used for position motors.
|
| Angular XAxis Motor Damping
| Damping when solving position target (0 = minimal damping, 1 = critical damping). Only used for position motors.
|
| Angular XAxis Motor Limit
| Force range to apply in case of a angular constraint (N). Usually this is -mMaxForceLimit unless you want a motor that can e.g. push but not pull. Not used when motor is an angular motor.
|
| Angular XAxis Motor Target
| The target value of the angular axis X motor. It is a velocity or a position depending the mode.
|
| Angular YAxis
| Angular Y-axis constraint mode.
|
| Angular YAxis Limit
| The limits of the angular axis Y.
|
| Angular YAxis Friction
| The friction of angular axis Y.
|
| Angular YAxis Motor
| The motor mode of angular axis Y.
|
| Angular YAxis Motor Frequency
| Oscillation frequency when solving position target (Hz). Should be in the range (0, 0.5 * simulation frequency]. When simulating at 60 Hz, 20 is a good value for a strong motor. Only used for position motors.
|
| Angular YAxis Motor Damping
| Damping when solving position target (0 = minimal damping, 1 = critical damping). Only used for position motors.
|
| Angular YAxis Motor Limit
| Force range to apply in case of a angular constraint (N). Usually this is -mMaxForceLimit unless you want a motor that can e.g. push but not pull. Not used when motor is an angular motor.
|
| Angular YAxis Motor Target
| The target value of the angular axis Y motor. It is a velocity or a position depending the mode.
|
| Angular ZAxis
| Angular Z-axis constraint mode.
|
| Angular ZAxis Limit
| The limits of the angular axis Z.
|
| Angular ZAxis Friction
| The friction of angular axis Z.
|
| Angular ZAxis Motor
| The motor mode of angular axis Z.
|
| Angular ZAxis Motor Frequency
| Oscillation frequency when solving position target (Hz). Should be in the range (0, 0.5 * simulation frequency]. When simulating at 60 Hz, 20 is a good value for a strong motor. Only used for position motors.
|
| Angular ZAxis Motor Damping
| Damping when solving position target (0 = minimal damping, 1 = critical damping). Only used for position motors.
|
| Angular ZAxis Motor Limit
| Force range to apply in case of a angular constraint (N). Usually this is -mMaxForceLimit unless you want a motor that can e.g. push but not pull. Not used when motor is an angular motor.
|
| Angular ZAxis Motor Target
| The target value of the angular axis Z motor. It is a velocity or a position depending the mode.
|
